Selection Table Of Potentiometers

Photo Series Circuit Mechanical Angle Detent Switch Travel Operating Life Catalog
RA09 Series_ insulated shaft Single-unit
Dual-unit
Quad-unit
45°
135°
280°
300°
0
1
11
21
N/A Rotational life: 10,000 cycles RA09 Potentiometer Insulated Shaft.pdf
RA09 Series_ metal shaft Single-unit
Dual-unit
Triple-unit
Quad-unit
120°
300°
0
1
11
21
41
0.5mm Rotational life: 10,000 cycles RA09 Potentiometer Metal Shaft.pdf
RA1150 Series Single-unit
Dual-unit
300° 0
1
21
N/A Rotational life: 15,000 cycles RA11 Insulated shaft rotary potentiometer.pdf
RA14 Series Dual-unit 300° 0
1
N/A Rotational life: 15,000 cycles RA14 Insulated shaft potentiometer.pdf
RA26 Series Single 360° 2 N/A Rotational life: 50,000 cycles RA26 Insulated shaft potentiometer.pdf
RB12 Series Single-unit
Dual-unit
300° 0
1
N/A Rotational life: 10,000 cycles RB12 Potentiometer with insulated shaft .pdf
RB16 Series Single-unit
Dual-unit
300° 0
1
N/A Rotational life: 10,000 cycles RB16 Potentiometer with insulated shaft .pdf
RA08 Series Single
Dual
Triple
300° 0 Rotary switch
N/A
Rotational life: 10,000 cycles RA08 Potentiometer metal shaft.pdf
RA1151 Series Dual 360° 0 N/A Rotational life: 20,000 cycles RA1151 Metal shaft rotary potentiometer.pdf
RD12 Series Single-unit
Dual-unit
300° 0
1
N/A Rotational life: 10,000 cycles RD12 Potentiometer metal shaft .pdf
RD16 Series Single-unit
Dual-unit
Duad
Hexa
300° 0
1
11
21
41
Rotary switch (N/A) Rotational life: 10,000 cycles RD16 Potentiometer metal shaft .pdf
RD24 Series_Metal shaft Single 300° N/A Rotary switch
(N/A)
Rotational life: 10,000 cycles RD24 Potentiometer metal shaft .pdf
RD24 Series_Insulated shaft Single 320° N/A Rotary switch
(N/A)
Rotational life: 10,000 cycles RD24 Potentiometer insulated shaft .pdf
RC08 Series Dual 120° N/A N/A Rotational life: 10,000 cycles RC08 potentiometer.pdf
RC10 Series Single
Dual
270° N/A N/A Rotational life: 10,000 cycles RC10 potentiometer.pdf
RC1003 Series Single
Dual
230° N/A N/A Rotational life: 10,000 cycles RC1003 potentiometer.pdf
RC15 Series Triple 270° N/A N/A Rotational life: 10,000 cycles RC15 potentiometer.pdf
PT10 Series Single-unit 240° 0
1
2
Rotary switch (N/A) Rotational life: R≤1KΩ, 2,000 cycles
R>1KΩ, 10,000 cycles
PT10 Potentiometer through shaft .pdf
PT15 Series Single 260° 0
13
Rotary switch (N/A) Rotational life: R≤1KΩ, 2,000 cycles
R>1KΩ, 10,000 cycles
PT15 Potentiometer through shaft .pdf
PT21 Series Single 360° 0 Rotary switch (N/A) Rotational life: 50,000 cycles PT21 Potentiometer through shaft .pdf
PT26 Series Single 360° 0 Rotary switch (N/A) Rotational life: 50,000 cycles PT26 Potentiometer through shaft .pdf
RJ12 Series Single 1.2mm N/A N/A Rotational life: 100,000 cycles RJ12 contact joystick potentiometer.pdf
RJ13 Series Single 26° N/A 0.5mm Rotational life: 2,000,000 cycles
Switch: 1,000,000
RJ13 contact joystick potentiometer.pdf
RJ16 Series Single 26° N/A N/A Rotational life: 100,000 cycles RJ16 contact joystick potentiometer.pdf
RJ1802 Series Single 2.0mm N/A N/A Rotational life: 100,000 cycles RJ1802 contact joystick potentiometer.pdf
RJ1803 Series Single 2.0mm N/A N/A Rotational life: 100,000 cycles RJ1803 contact joystick potentiometer.pdf
SC1505 Series Single
Dual
N/A 0
1
3
N/A Rotational life: 10,000 cycles 15mm slide potentiometer.pdf
20mm Travel Series Single
Dual
N/A 0
1
3
N/A Rotational life: 10,000 cycles 20mm slide potentiometer.pdf
30mm Travel Series Single
Dual
N/A 0
1
3
N/A Rotational life: 10,000 cycles 30mm slide potentiometer.pdf
45mm Travel Series Single
Dual
N/A 0
1
3
N/A Rotational life: 10,000 cycles 45mm slide potentiometer.pdf
60mm Travel Series Single
Dual
N/A 0
1
3
N/A Rotational life: 10,000 cycles 60mm slide potentiometer.pdf
100mm Travel Series Single N/A 0 N/A Rotational life: 10,000 cycles 100mm slide potentiometer.pdf
SV04 Series Single
Dual
N/A 0 N/A Rotational life: 10,000 cycles 4mm slide potentiometer.pdf
SV05 Series Single
Dual
N/A 0 N/A Rotational life: 10,000 cycles 5mm slide potentiometer.pdf
SV10 Series Single
Dual
N/A 0 N/A Rotational life: 10,000 cycles 10mm slide potentiometer.pdf
SM60 Series Single N/A 0 N/A Rotational life: 30,000 cycles 60mm motorized slide potentiometer.pdf
SM100 Series Single N/A 0 N/A Rotational life: 30,000 cycles 100mm motorized slide potentiometer.pdf
QA3901 Series Single 5D 180°
6D 190°
8D 225°
9D 180°/288°
17D 180°
29D 270°
5
6
8
9
17
29
N/A Rotational life: 30,000 cycles QA3901 Ring potentiometer.pdf
QA3902 Series Single 8D 225°
13D 180°
17D 220°
8
13
17
N/A Rotational life: 30,000 cycles QA3902 Ring potentiometer.pdf
QA48 Series Single 180° 9
17
N/A Rotational life: 30,000 cycles QA48 Ring potentiometer.pdf
